Benchtop Vibration Table

Vibration Testing for small components & electronics

The TCB-1.3 benchtop vibration chamber is ideal for reliability testing of compact products and electronics. It may be used as a stand-alone vibration table for vibration testing or placed inside an temperature chamber for combined random vibration & temperature testing offering flexibility and greater return on investment.

Equipped with an all-axis vibration system, the TCB-1.3 utilizes four pneumatically-actuated vibration hammers providing 6 dof, random vibration with x,y,z axis and roll, pitch and yaw rotation. The chamber comes standard with two accelerometers, one for control and one vibration monitor with a range of 1 to 60 GRMs.

Benchtop Vibration Quote

Benefits
Benefits of Vibration Testing
  • Quiet operation
  • Dual purpose - use for Vibration Testing only or place inside chamber for temperature/vibration testing.
  • Optional VibTrak software provides remote control and power spectrum density analysis.

Features
Vibration Controller

  • Specifications
  • Instrumentation
  • Cabinet

Model TCB
Workspace 16”W x 16”D x 10”H
(41cm x 41cm x 25cm)
Exterior Dimensions 33”W x 31”D x 23”H
(84cm x 79cm x 58cm)
Table Base 22”W x 25”D x 12”H
(56cm x 64cm x 30cm)
Temperature Range
(When used with environmental chamber)		 -70°C to +163°C (-94°F to +325°C)
Vibration Level 1 to 60 GRMS, 3 Hz to 10 kHz with unloaded table
Compressed Air <20 SCFM maximum @ 100 psi (689 kpa)
Overall Table Weight 200 lbs (90 kg)
Table Base: 120 lbs (54 kg)
Touch Screen Controller
  • CSZ EZT-570 Touch Screen Controller is designed to save chamber programming and setup time. Standard features data logging, data file access via memory stick or PC, Ethernet control and monitoring, alarm notification via email or phone text message, full system security, online help & voice assistance in multiple languages and more.
  • VibTrak™ software to operate both the CSZ environmental chamber and benchtop table. Provides the ability to control, profile, datalog, chart temperature/vibration and generate PSD curves.
  • Two accelerometers, one for control and one vibration monitor with 10ft cable
  • Audible & visual alarms
  • Independent vibration limit
Benchtop Vibration Table
  • The chamber features a stainless steel table base and powder-coated steel. Sound deadening materials are utilized on the inside of lid to reduce noise transmission of the vibration table. The chamber includes a base with removable control section and removable lid for optional placement inside an environmental chamber.
  • 16" x 16" (40cm x 40cm) vibration table with mounting locations on 2" centers
  • 2" (5 cm) circular access port
  • Four vibration generators
